Minimum size of graft:
SIZER-DISK FOR SIZER-DISK FOR On the back of the
PARTIAL PROSTHESES TOTAL PROSTHESES Sizer-Disk there are
With integrated BELL Expander recessed templates that
for expanding the bell foot indicate the minimum
size of transplants, e.g.
cartilage or fascia,
which is placed bet-
ween the prosthesis
head plate and the
tympanic membrane.
The central part of the
Sizer-Disk back features
a useful measurement
scale.
Sizer Total made of Cutting off the Sizer: Transport of the
plastic: It features With the fine Micro Sizer: The Sizer can be
recesses and length Scissors (REF 8000 172) transported with a fine
identification on the top the Sizer can be removed aspiration device that
as well as a stem for from the Sizer Disk in the sucks the head. Due
mounting on the stapes direct vicinity of the stem. to the plastic the Sizer
footplate. is extremely light and
therefore easy to
1 2 3 handle.
Length determination: Transport of the Length adjustment and
Sizer Total is placed on TTP-VARIAC: The prosthe- fixation of the head plate:
the stapes footplate to sis is wetted with a drop The prosthesis along with
intraoperatively deter- of saline solution before the head plate is placed in
mine the optimal length removal out of the primary the recess of the Sizer-Disk
of the titanium prosthesis package. You may use that corresponds to the
to be implanted later. the Titanium Tweezers determined length. With the
By means of adhesion (REF 8000 136) or a fine aid of Micro Closing Forceps
4 the Sizer remains stable 5 aspiration device to lift the 6 (REF 8000 137) the head
during measurement. prosthesis by its head plate. plate is firmly clamped.
Removal of stem: The Projecting pin: When Finished prosthesis:
projecting stem is re- the stem has been cut The finished TTP-
moved with Cutting off, a pin remains above VARIAC prosthesis is
Forceps (REF 8000 171). the head plate. Its now ready for implan-
It can thus be severed purpose is fixation of the tation.
easily and with high graft, which is placed
precision. between the prosthesis
head plate and the
7 8 tympanic membrane. 9
ACCESSORIES REF
Titanium Tweezers 8000 136
Titanium Micro Closing Forceps 8000 137
Cutting Forceps, stainless steel 8000 171
Micro Scissors, stainless steel 8000 172
Tray TTP-VARIAC 8000 173
Resterilizable
Important! For full information the Instruction For Use must be read
